Potter HS24-177W 24 VDC Fixed Candela, Low Profile Evacuation Horn, Strobe, White

Potter HS24-177W 24 VDC Fixed Candela, Low Profile Evacuation Horn, Strobe, White

$80.11
$80.11
Sale Special Order
Shipping calculated at checkout.

Special order — estimated 2–6 weeks lead time.
View full details
The S/HS24-177 Series is a low profile strobe, or horn/strobe combination that offers dependable audible and visual alarms with the absolute lowest current available. The S/HS24-177 Series has a minimum flash rate of 1Hz regardless of input voltage. The S/HS24-177 Series is shipped with the standard 4" mounting plate which incorporates the popular Super-Slide feature that allows the installer to easily test for supervision.
The product also features a locking mechanism which secures the product to the bracket without any screws showing. The S/HS24-177 Series also features the patented Checkmate -Instant Voltage Verification feature which allows the installer to measure the voltage drop and match it to the blueprint. The S/HS-177 Series appliances are ANSI/UL 464, ANSI/UL 1971 and/or ANSI/UL 1638 listed for use with fire protective systems and are warranted for five years from date of purchase.

Main Features

  • Nominal Voltage 24 VDC
  • Fixed177 candela strobe
  • Super-Slide Bracket - ease of supervision testing
  • Checkmate - Instant voltage verification
  • Unit Dimensions: 5" (12.7 cm) high x 4.5" (11.43 cm) wide x 2.5" (6.35 cm) deep.
  • Synchronize strobe and/or horn with AVSM Control Module
  • Pre wire entire system, install mounting bracket, then install signals
  • Documented lower installation and operating costs
  • Input terminals 12 to 18 AWG
  • Switch selection for high or low dBA
