iEi Electronics PIP24VDCRU Regulated DC Output Power Supply

Linear PIP24VDCRU

Plug-in power supply, EISA compliant, auto-resetting poly fuse, 120 VAC input, 24 VDC output @ 1000 mA (1 amp) maximum. Plug-in-Power supply provides regulated 24VDC 24W output from 100/240Vac input. Includes auto-resetting poly fuse, robust surge protection and EISA Energy efficiency Level IV compliant.

Features

• Output voltage regulated at ±1% from 0% to 100% load, expands options for use in low-load and high-load applications
• Poly-fuse automatically resets after a short circuit, prevents unnecessary service calls
• Ground prong on AC power input and ground output terminal, provides input protection and easy panel ground connection
• Robust surge protection, prevents AC line spikes and transients from harming the power supply or the connected equipment
• Red LED power indicator, shows at a glance that the supply is operating
• Plugs directly into AC outlet, knockout for wall outlet retaining screw, easy and quick to install
• Acts as transformer and power supply in-one, no cabinet to mount
• Dimensions: 2.5″ W x 3.5″ H x 2.25″ D
