HES 5200-12/24D-630 Electric Strike Body, 12/24VDC, 0.24/0.12A, 1-3/16" Depth, for 5200 Series Electric Strike Electric Strike, Includes Smart Pac III, Faceplates (J, KD, KM, HM, ND) and Brackets, Satin Stainless Steel

HES 5200-12/24D-630 Electric Strike Body, 12/24VDC, 0.24/0.12A, 1-3/16" Depth, for 5200 Series Electric Strike Electric Strike, Includes Smart Pac III, Faceplates (J, KD, KM, HM, ND) and Brackets, Satin Stainless Steel

$149.21
$149.21
Sale Special Order
Shipping calculated at checkout.

View full details
The 5200 series electric strike features an in-frame horizontal adjustable design to simplify the installation process. This features allows the installer to easily adjust the electric strike opening to accommodate the horizontal position of the latchbolt after the strike has been installed.
This field selectable fail secure/fail safe unit is easy to install and accommodates latchbolts up to a 3/4" throw. The 5200 is also available in a Complete Pac which pairs the strike body with the faceplates and mounting hardware all in one simple convenient package.

Main Features

  • Tamper resistant
  • Static strength 1,500 lbs
  • Dynamic strength 70'- lbs
  • Endurance 500,000 cycles
  • Field selectable fail secure/ fail safe
  • Dual voltage 12 or 24 VDC/VAC
  • Non-handed
  • Internally mounted solenoid
  • Accommodates 5/8" - 3/4" latchbolt (3/4" with 1/8" door gap)
  • Strike body depth 1-1/16"
