George Risk Industries
GRI 29PAWG-B 29P Series Standard Surface Mount Magnetic Reed Switch Set with Pre-Wired 24" Lead, Wide Gap, Open/Closed, SPDT, C, Brown, Individually Bagged
GRI 29PAWG-B 29P Series Standard Surface Mount Magnetic Reed Switch Set with Pre-Wired 24" Lead, Wide Gap, Open/Closed, SPDT, C, Brown, Individually Bagged
Regular price
$92.38
Regular price
Sale price
$92.38
Shipping calculated at checkout.
Special order — estimated 2–6 weeks lead time.
Quantity
Couldn't load pickup availability
This series offers a standard gap of 1 inch, a wide gap of up to 1 1/2 inches and an extra wide gap of 2 inches and can be installed on a steel surface with a minimum gap penalty. The "P" style is a pre-wired switch with 2 feet of conductor cable. A broad range of mounting brackets are also available.
Main Features
- Lifetime warranty against workmanship, material and factory defects
- UL and ULC approved
- Concealed terminals on 28 Series
- 24" jacketed cable on PA Series
- Longer leads upon request on PA series
- Side mounted screw terminals on 29 series
- Standard gap up to 1" , 5/8" on steel
- Wide gap up to 1 1/2" , 3/4" on steel
- Extra wide gap up to 2" , 1" on steel
- Spacers, covers and screws Included
