• Push to exit button with green border on a white background
1 1

Camden

Camden CM-9800/7 Illuminated Request to Exit Button

Camden CM-9800/7 Illuminated Request to Exit Button

MPN: CM-9800/7

$148.93
$148.93
Sale Special Order
Shipping calculated at checkout.

Special order — estimated 2–6 weeks lead time.

Special Order

Out of stock
View full details
CM-9800 Series surface mount capacitive touch switches, with LED illumination, are vandal and weather resistant with IP 66 rating. The units feature a cast metal design and an adjustable 0 to 60 second relay timer. The CM-9800 has an external input, so that the switch illumination may be activated by either the switch status or the door (locked) status. The large surface area of the capacitive switch is easy to activate, with only a light touch, and the large LED light illumination enables the switch to be highly visible in low light conditions.

Main Features

  • Capacitive 'light touch' technology. No moving parts
  • ADA and ROHS Compliant
  • Weather and vandal resistant. IP 66 rated
  • Large LED Light Ring, RED, GREEN/ORANGE/NONE
  • Switch status or door status illumination (External input)
  • Hold Open relay timer, selectable 0 to 60 seconds
  • Heavy duty Form 'C' relay, rated 2 Amps
  • Tamper alarm
  • 12/24V, AC/DC
