Potter

Potter OSYSU-1 Outside Screw and Yoke Valve Supervisory Switch (Single Switch)

Potter OSYSU-1 Outside Screw and Yoke Valve Supervisory Switch (Single Switch)

$121.98
$121.98
Sale Special Order
Shipping calculated at checkout.

View full details
The OSYSU is used to monitor the open position of an OS&Y (outside screw and yoke) type gate valve. This device is available in two models; the OSYSU-1, containing one set of SPDT (Form C) contacts and the OSYSU-2, containing two sets of SPDT (Form C) contacts. These switches mount conveniently to most OS&Y valves ranging in size from 2” to 12” (50mm to 300mm). They will mount on some valves as small as ½” (12,5mm). The cover is held in place by two tamper resistant screws that require a special tool to remove. The tool is furnished with each device.

Main Features

  • NEMA 4X(IP 65) and 6P (IP 67)
  • Enclosure is 4X. For additional corrosion protection of mounting hardware, use model OSYSU-2 CRH
  • -40º to 140º (-40ºC to 60ºC) operating temperature range
  • Visual switch indicators
  • Two conduit entrances
  • Adjustable length trip rod
  • Accomodates up to 12AWG wire
  • Three position switch detects tampering and valve closure
  • Knurled mounting bracket prevents slipping
